Manual PCB Depaneling Machine for V-Cut Panels

SDM101 Manual PCB Depaneling Machine for V-Cut Panels

The SDM101 Manual Depaneler is a cost-effective solution designed for small to medium volume PCB production. Ideal for pre-scored boards, this manually operated system allows the user to align the score line with the linear blade and smoothly draw the circular blade across the PCB for safe and efficient separation. The process minimizes mechanical stress on the board, helping to prevent solder joint cracks and ensuring long-term reliability of the assembly.

The combination of circular and linear blades allows for precise separation of both large and small boards—even those with components projecting across the score line. Blade height is fully adjustable, accommodating a variety of board thicknesses and component placements. For added flexibility, blades can also be custom-made to meet specific production requirements, making the SDM101 series a versatile and dependable solution for low-maintenance PCB depaneling.

Max Cut Length

445 mm (17.5 in.)

483 mm (19 in.)

or for pricing

[{"id":40316112994443,"title":"445 mm (17.5 in.)","option1":"445 mm (17.5 in.)","option2":null,"option3":null,"sku":"SDM101-445","requires_shipping":true,"taxable":true,"featured_image":null,"available":true,"name":"SDM101 Manual PCB Depaneler - 445 mm (17.5 in.)","public_title":"445 mm (17.5 in.)","options":["445 mm (17.5 in.)"],"price":749500,"weight":170097,"compare_at_price":null,"inventory_management":"shopify","barcode":"","requires_selling_plan":false,"selling_plan_allocations":[],"quantity_rule":{"min":1,"max":null,"increment":1}},{"id":40316113027211,"title":"483 mm (19 in.)","option1":"483 mm (19 in.)","option2":null,"option3":null,"sku":"SDM101-483","requires_shipping":true,"taxable":true,"featured_image":null,"available":true,"name":"SDM101 Manual PCB Depaneler - 483 mm (19 in.)","public_title":"483 mm (19 in.)","options":["483 mm (19 in.)"],"price":899500,"weight":170097,"compare_at_price":null,"inventory_management":"shopify","barcode":"","requires_selling_plan":false,"selling_plan_allocations":[],"quantity_rule":{"min":1,"max":null,"increment":1}}]

Questions? Reach Out Directly:

Chris Ellis - East Coast

Sales & Operations Manager

215.869.8374

Ed Stone - West Coast

Sales Manager

215.808.6266

Description Protect_msd Restore_and_store Specifications Features Feeders Machine_configurations Applications Profile_predictions Performance_charts Video Navigator_software Process_window Add_ons Temperature_tolerance Includes Add_fluxing Contact

The design of the SDM101 eliminates stress on the board and the components during the separation process, preventing post-breakout-related board, component and solder joint defects even when components are located as close as 1 mm to the scoring line. SDM101 can be used with panels that are v-scored in the X direction or X & Y directions and PCB thicknesses from 0.8 mm to 3.0 mm. The large processing table can be angled to permit processed boards to fall away. This low-maintenance PCB separator requires no power or air for $0 utility costs and the ability to use the machine anywhere in the facility. Sturdy, heavy-duty design. A shatterproof Plexiglas safety shield protects operator from cutting blade.

SDM101 SPECIFICATIONS
PCB Thickness	0.8-3.0 mm
Max PCB Width	Unlimited
Max PCB Length	17.5" (445 mm) 19" (483 mm) Optional
Score Angle	20˚
Minimum Component Distance to V-Groove	1 mm
Max Component Height	1.26" (32 mm)
PCB Materials	Anything but Aluminum
Separating Speed	Operator Dependent
Depaneling Mode	Manual
Production Volume	Moderate
Power	N/A
Dimensions	29.5" x 9.4" x 18.4" (750 x 240 x 742 mm) Process Table: 19.7" x 6.5" (500 x 165 mm)
Net Weight	Standard Size with 445 mm Cut Length: 70.5 lbs (32 kg) Large Size with 483 mm Cut Length: 88 lbs (40 kg)
Shipping Weight	Standard Size with 445 mm Cut Length: 146 lbs (66 kg) Large Size with 483 mm Cut Length: 163 lbs (74 kg)
